Type CM-3 Super Strength Conveyor Magnet

Description Clients Who Use Our Conveyor Magnets CM3 Conveyor Magnet Specifications Size Magnetic Surface Area Sq. Inches Depth in Inches Width in Inches Height in Inches Weight (lbs) Lifting Power* CM3-18 180 10 18 3 67 300 Lbs. CM3-24 240 10 24 3 90 400 Lbs CM3-30 300 10 30 3 112 500 Lbs. CM3-36 360 10 36 3 135 600 Lbs. CM3-48 480 10 48 3 180 800 Lbs. *Lifting Power Measured using a Flat Steel Plate Benefits Industrial-strength conveyor magnet lifts items up to 3″- 4″ below unit We use only Grade 8 Permanent Magnets, the strongest permanent magnets available in all of our magnetic products. Designed to remove damaging ferrous metal debris and provide optimal safety conditions on conveyors, chutes and areas where metal contamination is a problem. Reduces damage to processing equipment. All weather durability and service — no maintenance required. Heavy duty construction consists of state-of the-art permanent magnets, double bonded, and encased in a stainless steel channel and heavy-gauge carbon steel backplate. LIFETIME GUARANTEE ON MAGNETIC STRENGTH/PRODUCT PERFORMANCE GUARANTEE. Applications Aggregate Processing Food Processing Sand & Gravel Quarries Recycling Tire Shredding
